PM Stepper motor Bipolar 12 VDC 9.8 Ω step angle 15° 2-2 Phase
Description
Automobile water valve motor
Performance Parameters:
Rated voltaje: 12 VDC
Step angle: 15°
Excitation Mode: 2-2 Phase
Drive method: Bipolar
Phase Current: 420mA
Phase Resistance: 9.8 ?
Detent Torque: 6 mN·m
Holding Torque: ? 19 mN·m
Dielectnic strength: 1? (max)
Noise: ? 40 dba
Working Temperature: -30 ? 90 °C
