ABB OS30FAJ12 Disconnect Switch, 600 VAC, 3 hp, 30 A, 3 Poles
Availability: Pre-Order, Inquiry Price
About this product
*Is Discontinued By Manufacturer : No
*Item Weight : 1.69 Pounds
*Item model number : OS30FAJ12
*Date First Available : March 29, 2016
*Manufacturer : ABB Group
Description
ABB PowerLine fusible 3-pole disconnect switch has 600 VAC voltage rating and 30 A amp rating with a power rating of 3 hp. Brand Name|ABB#MFR Part Number|OS30FAJ12#UPC|804325415842#UNSPSC|39122233#Item|Disconnect Switch#Type|Fusible, Front Operated#Series|PowerLine, OS#Voltage Rating|600 VAC#Power Rating|3 HP at 240 VAC 1-Phase, 2 HP at 120 VAC 1-Phase, 20 HP at 600 VAC 3-Phase, 15 HP at 460/480 VAC 3-Phase, 7.5 HP at 230/240 VAC 3-Phase#Amperage Rating|30 A#Number of Poles|3#Mounting Type|Base/DIN-Rail#Terminal Type|Screw#Dimensions|100 mm Height x 143 mm Width x 119 mm Depth#Standard/Approvals|CSA 22.2 No 4, IEC Approved, UL 98
