EPEVER 30A Solar Charge Controller MPPT Solar Panel Charge Controller 12V / 24V Auto Working Max PV 100V Solar Charge Battery Regulator with LCD Display for Gel Flooded Sealed Lithium Batteries

EPEVER 30A Solar Charge Controller MPPT Solar Panel Charge Controller 12V / 24V Auto Working Max PV 100V Solar Charge Battery Regulator with LCD Display for Gel Flooded Sealed Lithium Batteries

Name: EPEVER 30A Solar Charge Controller MPPT Solar Panel Charge Controller 12V / 24V Auto Working Max PV 100V Solar Charge Battery Regulator with LCD
Brand: EPEVER
SKU: MM30196
Availability: InStock

Brand: EPEVER
Product Code: MM30196
Availability: Pre-Order, Inquiry Price

US$0.00

- +

For Bulk Order, Get Better Price.

About this product

*This controller uses the most advanced MPPT technology to ensure high efficiency (>98%) of your solar system. Significantly outperforms standard PWM controllers. Ultra-fast tracking speed and guaranteed tracking efficiency, advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time.

*Built-in LCD screen displays key charging parameters. Multiple connectivity options for the controller (remote meter, mobile app, PC software etc) enable the user to personalise each charging stage, create a user-defined battery type with specific parameters and access exclusive settings.

*Multiple protections eliminate safety hazards, low voltage input protection, over voltage input protection, over charge power protection, low voltage output protection, rated output current protection, temperature protection, PV and battery reverse connection protection.

*With Modbus communication protocol interface, full-load operation without any drop in capacity within the range of working environment temperature, it is convenient for customers to expand applications and monitor in various fields like telecommunication base station, household system, street lighting system, wilderness monitoring system, etc.

*Compatibility with multiple battery types for convenient use, support Sealed lead acid, gel, flooded, lithium and users. Suitable for solar panels up to 390W (12V battery or battery bank) or 780W (24V system). Current limiting function (30A) allows possibility of adding more solar panels in the future.

Description

The Tracer AN series. Based on common negative design and advanced MPPT control algorithm, with LCD displaying running status, this product is artistic, economical and practical.The limitation function of the charging power and current and reducing charging power function automatic improve the stability which works even connecting oversize PV modules and in high temperature, and increase the professional protection chip for the communication port, further improving the reliability and meeting the different application requirements.With the adaptive three-stage charging mode based on a digital control circuitThis modular solar controller can be widely used for different applications, e.g., Communication base stations, household systems, and field monitoring, etc.The communication port adopts professional protection chip, which can provide 5VDC power supply, and has over-current and short-circuit protectionWith RS-485 communication bus interface and Modbus communication protocol, it is available to meet various communication requirements in different situationsMonitor and set the parameters via mobile phone APP or PC softwareFull-load operation without any drop in capacity within the range of working environment temperatureAdvanced MPPT technology, with efficiency no less than 99.5%Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss timeWide MPP operating voltage rangeInternational famous brands of ST and IRs components of high quality and low failure rate are used, which can ensure the product?s service lifeCompatible with lead-acid and lithium-ion batteriesExtensive electronic protection Charging power and current limitation function Battery temperature compensation function Real-time energy statistics function Overheating power reduction function Multiple load work modes Charge Rated Current:30ASystem Voltage:12V/24V auto workVoltage: 100VConsumption: ?12mABattery Voltage Range: 8V ~ 32VRS485 communication interface: 5VDC/100mAGrounding type: Negative groundBattery types: Gel battery, Sealed lead-acid battery, Flooded battery, lithium battery, User-defined.

Tags: solar charge controller, MPPT solar charge controller, 12V 24V solar charge regulator, lithium battery charge controller, solar panel controller, EPEVER charge controller, battery management system, solar power system, off-grid solar, solar energy system
