Stepper Motor Drive Simple Controller Speed Reversing Control Pulse PWM for 3D Printing
Availability: Pre-Order, Inquiry Price
About this product
*We are a professional Electronic Components and module manufacturer. You can search keywords in our store. I believe you can find the modules you need.
*Test before shipping.
*USA and Canada Estimated Delivery Time: 6-24 days(trackable),----- We provide Expedited Shipping service : 3-8 days.(excluding handling time).If the order amount above US $150, we will use Expedited Shipping service for free.
*We make every effort to provide customers with satisfactory service.any question,please feel free to contact me.
*We are a professional Electronic Components and module manufacturer. You can search keywords in our store. I believe you can find the modules you need.
Description
Product Introduction:
1. This module is a pulse generating module, which supplies as a signal for stepper drivers. To control the stepper motor, it must be equipped with the driver.
2. Easy controller + stepper driver + stepper motor + DC power composed a simple control platform.
3. The controller consists of 3 kinds of frequency signal, including 5.4k-160khz, 540-16.6khz, 80-2.4khz, which can be chose by skipping stitch.
4. Support generating a pulse and PWM signal ,support skipping stitch choice.
5. Frequency measurement: the two ports of PUL and common-cathode (or common anode) can be measured .
Different stepping motor driver different port sign, but same function
EN=ENA=FREE Enable
PUL=PULS=CLK Pulse
DIR=CW=CWW Direction
Common anode connection (connect with B)
EN+ PUL+ DIR+ all link together to common anode port
EN- connect to EN
PUL- connect to CLK
DIR- connect to DIR
Common cathode connection (connect with B)
EN- PUL- DIR- all link together to common cathode port
EN+ connect to EN
PUL+ connect to CLK
DIR+ connect to DIR
Package includes:
1 x Stepper Motor Driving Controller
