SUTK Stepper Motor Driving Controller Pulse PWM Speed Reversing Control for 3D Printer
About this product
*1.This module is a pulse generating module,which supplies as a signal for stepper drivers.To control the stepper motor,it must be equipped with the driver.
*2.Easy controller +stepper driver +stepper motor +DC power composed a simple control platform.
*3.The controller consists of 3 kinds of frequency signal,including 5.4k-160khz,540-16.6khz,80-2.4khz,which can be chose by skipping stitch.
*4.Support generating a pulse and PWM signal,support skipping stitch choice.
*5.Frequency measurement:the two ports of PUL and common-cathode(or common anode)can be measured.
Description
Product Introduction:
1.This module is a pulse generating module,which supplies as a signal for stepper drivers.To control the stepper motor,it must be equipped with the driver.
2.Easy controller +stepper driver +stepper motor +DC power composed a simple control platform.
3.The controller consists of 3 kinds of frequency signal,including 5.4k-160khz,540-16.6khz,80-2.4khz,which can be chose by skipping stitch.
4.Support generating a pulse and PWM signal,support skipping stitch choice.
5.Frequency measurement:the two ports of PUL and common-cathode(or common anode)can be measured.
Different stepping motor driver different port sign,but same function
EN=ENA=FREEÂ Enable
PUL=PULS=CLKÂ Pulse
DIR=CW=CWWÂ Direction
Common anode connection(connect with B)
EN+ PUL+ DIR+ all link together to common anode port
EN-connect to EN
PUL-connect to CLK
DIR-connect to DIR
Common cathode connection(connect with B)
EN- PUL- DIR-all link together to common cathode port
EN+ connect to EN
PUL+connect to CLK
DIR+connect to DIR
