DC Speed Control, 90/180VDC, 10A, NEMA 4/12
Product Code: MM26816
Availability: Pre-Order, Inquiry Price
Availability: Pre-Order, Inquiry Price
About this product
*0-180 VDC
*0-90 VDC
*1 PH
*1/4-2 HP
*1/8-1 HP
Description
'DC Speed Control, Enclosure Chassis, Max. Amps 10, Voltage Output 0 to 90/180VDC, Speed Range 50:1, Rotation Reversable, External Switches CW/CCW, AC Input Voltage 120/240VAC, DC Speed Control SCR, HP @ Lower Volts 1/8 to 1, HP @ Higher Volts 1/4 to 2, Linear Acceleration Adjustable 0.5 to 8 sec., Current/Torque Limit Adjustable, Speed Regulation +/-1 Percent with Armature Voltage Feedback, +/-0.5 Percent with Tach Feedback, Shunt Wound Volts 100/200VDC, Accepts Tach Feedback Yes'
