Gumps grocery Stepper Motor Driver TB6600 4A Nema 23 Nema 34 42/57/86 Nema17 4A DC9-40V

Features :
This drive is an upgraded version
TB6600, the highest segments to 32, fit for high subdivision applications.
Applicable stepper motor: 42,57,86 type 2 phase 4-phase (4-wire 6 wire line 8)
1, 9V-42V DC supply;
2, H-bridge bipolar constant phase flow driven;
3, eight output current optional, the maximum output current: 4.0A;
4, 6 subdivision modes available,up to 32 segmentse;
5, the input signal high-speed optical isolation;
6, common anode single pulse interface standard;
7, offline hold function;
8, semi-enclosed chassis can adapt to more hard environment;
9, provide energy-efficient semiautomatic current lock function;
10, built-in temperature protection and overcurrent protection.
