BEMONOC Reversible Mirco Dc Worm Geared Motor 12V 55 RPM Double Shaft Output 8mm with Gear Box for Diy Parts
Share Facebook Twitter Pinterest Email

BEMONOC Reversible Mirco Dc Worm Geared Motor 12V 55 RPM Double Shaft Output 8mm with Gear Box for Diy Parts

Brand: ‎BBQ Driver
Product Code: MM3825
Availability: Pre-Order, Inquiry Price
US$0.00
- +

About this product

*✔Rated voltage: DC12V; No-load speed: 55RPM; Rated torque: 7.5kg.cm; Stall Torque: 18kg.cm; Rated Current: 1.1A; Reduction ratio:1/101;

*✔Protection class: IP54; Low noise: db

*✔DC Motor Body Dimensions: 31 x 57mm/ 1.22" x 2.24"(D*L); Gear Box Dimensions: 58.1 x 40.1 x 35mm/ 2.28"x1.58"x1.37"(L*W*H)

*✔Output Shaft Dimensions: 8 x 15mm/ 0.31" x 0.59"(D*L) with 1x 13mm/ 0.039*0.51(H*L) flat cut off; Wire Length : 19mm/7.4";

*✔Package: 1PCS x DC Geared Motor; if you need other voltage and rpm, pls contact us, there are many other models of this motor in store.

Description

This type is miniature Worm Gear DC Motor, which can change shaft rotation direction while the wiring positive and negative be changed.It's also have addition two characteristics:

(1)With self-locking, the output shaft can't rotation when switch off, that is self-locking.

(2) Gearbox output shaft and motor shaft are come to be a rectangle, it's widely used in various of occasions that require special install size.
