DC 12V Gear Box Motor, CW/CCW Reversible High Torque Worm Geared Motor (40RPM)
Availability: Pre-Order, Inquiry Price
About this product
*WELL DESIGNED: No self‑locking, working well
*WELL DESIGNED: No self‑locking, working well
*SPECIFIC FEATURE: The gearbox output shaft direction of the motor shaft is arranged vertically
*SUITABLE FOR: Widely used in windows, a door opener, miniature winch and other occasions
*VARIETY OF CHOICES: No-load speed choice : 5rpm / 6rpm / 20rpm / 40rpm / 62rpm
Description
Description:
The entire body of the motor output shaft relative to the general direction of gear motor short, widely adapted to some of the installation dimensions of this aspect is required.
Features:
1. No self-locking, working well
2. The gearbox output shaft direction of the motor shaft is arranged vertically
3. Suitable for: Widely used in windows, a door opener, miniature winch and other occasions
Specifications:
Voltage: DC12V
Load torque: 10KG.CM
No-load speed choice : 5rpm / 6rpm / 20rpm / 40rpm / 62rpm(optional)
Speed(RPM) Stall Torque(kg.cm) Stall Current(A) No-load Current(A) Reduction Ratio 5 36.4 0.82 0.12 1:972 6 36.4 0.82 0.12 1:972 20 28.2 1.14 0.22 1:400 40 15 1.15 0.31 1:224 62 16 2.52 0.41 1:224Â
Package contain:
1 x Geared Motor
Note:Please note that the new type and old type of this product willbe sent randomly, and make sure you will not mind before ordering.
