30A DC 6-60V PWM Motor Speed Controller Board Dimmer Current Regulator+Display W329
Availability: Pre-Order, Inquiry Price
About this product
*The product quality is good.
*We are a professional Electronic Components and module manufacturer. You can search keywords in our store. I believe you can find the modules you need.
*USA and Canada Estimated Delivery Time: 6-24 days(trackable),----- We provide Expedited Shipping service : 3-8 days.(excluding handling time).If the order amount above US $150, we will use Expedited Shipping service for free.
*any question,please feel free to contact me.
*We make every effort to provide customers with satisfactory service.
Description
Descriptions:
This is a simple and easy-to-use DC motor speed controller of small size, elegant appearance and stable performance. It is made with high quality circuit board which ensures a longer service life. The current can be adjusted from 0A to 30A which is quite convenient to set.
Features:
Speed controller is made with high quality circuit board which ensures a longer service life.
This simple and easy-to-use DC motor speed controller has an stable performance.
The output current of this motor speed controller can be adjusted from 0A to 30A, and it is simple to set.
Designed with a digital display that shows the rate in percent of actual speed to maximum speed.
This motor speed controller uses screw terminals for convenient and quick wiring.
The positive and negative pole of controller must be connected correctly, otherwise, the item might be burnt.
The input voltage of controller is better to be same as rated voltage of motor.
Specifications:
Input Voltage: DC 6V-60V
Output Voltage: Linear with load (voltage drop at motor 2 terminals )
Output Current: 0A-30A
Continuous Current: <20A
Speed Range: 0% to 100% (variable)
Regulation Method: Potentiometer (Linear)
Regulation Type: Regulating Current (cannot be used as a voltage regulator)
Control Frequency: 15KHz (pulse width)
Wiring Type: Screw terminal
Rotary Knob: 100K with switch (270°)
Size: 75x56mm/2.95x2.2"
Quantity: 1 Pc
Note:
Please allow 1-3mm error due to manual measurement.pls make sure you do not mind before you bid
Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!
