Loulensy 3-Phase AC Voltage Transducer Sensor Transformer Transmitter 3-input 0-250V AC with 3-output 0-10V DC

Loulensy 3-Phase AC Voltage Transducer Sensor Transformer Transmitter 3-input 0-250V AC with 3-output 0-10V DC

Product Code: MM27922
Availability: Pre-Order, Inquiry Price

US$0.00

- +

For Bulk Order, Get Better Price.

About this product

*Input:0-250V AC

*Capacity Max:0-500V AC (Customerized,contact operator if you need other input ranges,e.g.0-75mV or 0-300V)

*Impulse Voltage:5KV(peak value),1.2/50uS

*Response Time:=/< 300mS

*Default Frequency:40-60Hz(contact us,if you specially need different frequency,e.g. 100Hz)

Description

This voltage transducer combines a potential transformer and signal conditioner, and is suitable for use in industrial automation systems. The transducer provides average root-mean-square (RMS) measurement for sinusoidal alternating voltage waveforms, with an accuracy of 0.5% full scale (FS) and a response time of 300 ms or shorter. Mounting options include DIN rail or panel. It is suitable for monitoring linear, constant-speed loads that produce sinusoidal waveforms.

Warranty & Return
1.24 MONTHS QUALITY guarantee. Warranty : In the process of Exchanging products Buyer shoud bear freight of return shipping, while Manufactuer should bear freight of sending.
2.Buyer can return products and get FULL REFUND of item value within 30 days after receiving , if there's any quality problem in original products; Freight of return should be beard by manufacturer.
