Speed Controller, DC 10-50V 100A Motor Speed Controller PWM Control Switch Governor for Car Cooling Fan Motor, Exhaust Blower, Car Air Conditioning Motor
Availability: Pre-Order, Inquiry Price
About this product
*PARAMATER--- Operating temperature:-20 to 40.It can perform normally when the temperature is below 0; Control power: 0.01W to 5000W;PWM Duty Cycle:0%-100% and Quiescent current is 0.04A( not over 40mA when voltage is DC10V to DC30V)
*WORKING VOLTAGE--- DC 10-50V;Max.rated current60;APeak current100A; The input voltage must differentiate "+" ,"-",The input voltage should be equal to the rated voltage of the motor within 10-50V,or it will be burnt.
*APPLICATION--- Universal speed controller can be used for DC brush motor, suitable for car cooling fan motor, car air conditioning motor, exhaust blower, treadmill motor, etc; This motor speed controller can also be used for dimming DC lamps or controlling DC heater
*QUALITY ASSURANCE: If you are not satisfied with the product, please feel free to contact us, We will tries our best to improve product quality and peace of mind 100% satisfaction service.
Description
Description:
This is a simple and easy-to-use DC motor speed controller of elegant appearance and stable performance. It is made with high quality circuit board which ensures a longer service life. The input voltage can be DC 10V to 50V and control power from 1200W to 5000W(peak). This speed controller is a universal one which can be used on many DC brush motors in car cooling fan motor, car air conditioning motor, exhaust blower, etc.
Specifications:
Working Voltage: DC10V to DC50V
Max. Rated Current: 60A
Peak Current: 100A
Control Power: 0.01W to 5000W
Power Alters According to Voltage:
12V*100A =1200W
24V*100A =2400W
30V*100A =3000W
50V*100A =5000W(peak)
Quiescent Current: 0.04A( not over 40mA when voltage is DC10V to DC30V)
PWM Duty Cycle: 0%-100%
PWM Frequency: 15khz
Operation Temperature: -20 to 40?
Size: 14.6 x 8 x 3.8cm / 5.74 x 3.15 x 1.49"
Package Includes:
1 x Speed Controller
