TDRFORCE 3/4 HP Water Pressure Booster Pump 110V Inline Water Transfer Pump Automatic Self Priming Irrigation Pump Shallow Well Jet Pump Household Booster Pump

CAUTION:

CAUTION: CAUTION:

Package Content:

Body Materials: Stainless steel, PPOVoltage: 115V Current: 5.4APower: 370W(1/2Hp) Max Pressure: 44PSIFrequency: 60Hz Speed: 2850rpmCapacitor: 20UFPipe Size: 1”×1”Max.Head: 32m(104ft)Product Weight: 9.1kg/20lbMax Flow(Liters/Min): 55L/Min(14.5GPM)CE, IP45 Protection, Insulation Class BBody Materials: Stainless steel, PPOVoltage: 115V Current: 6.8APower: 550W(3/4Hp) Max Pressure: 52PSIFrequency: 60Hz Speed: 2850rpmCapacitor: 30UFPipe Size: 1”×1”Max.Head: 34m(111ft)Product Weight: 12.05kg/26.56lbMax Flow(Liters/Min): 65L/Min(17GPM)CE, IP45 Protection, Insulation Class BBody Materials: Stainless steel, PPOVoltage: 115V Current: 9.2APower: 750W(1 Hp) Max Pressure: 60PSIFrequency: 60Hz Speed: 2850rpmCapacitor: 30UFPipe Size: 1”×1”Max.Head: 42m(137ft)Product Weight: 13.1kg/28.8lbMax Flow(Liters/Min): 65L/Min(17GPM)CE, IP45 Protection, Insulation Class BLiquid Requirements: Clean liquids without suspended solids, non-aggressive (Liquid temperature: -20?~+40?). Not recommended for sand point applications and please avoid sand pumped into pump body.If the pump remain unused for a long period of time, please empty it to prevent formation of deposits or increase of water volume due to frozen water, which could tear the fixing bolts or cracking the pump body.When starting the pump again, refill it and check that the shaft runs free by introducing a screw-driver into the slot on the shaft, on the fan side.Please carefully read over the operation manual before use for the sake of its proper application and optimum efficiency.1 x Pressure Boost Pump with Automatic Pump Control1 x Valve 1 x Connector1 x Teflon tape1 x American standard thread adapterInstruction Book
