WS2812B ECO LED Strip,BTF-LIGHTING Chasing Effects 5050SMD Individually Addressable 3.3FT 144(2X72) Pixels/m Flexible White FPCB Dream Color IP30 Non-Waterproof for Bedroom DIY Projects DC5V

Features

Addressable

Addressable

Cuttable

Cuttable

DIY Project

DIY Project

Easy to install

Easy to install

Adhesive

Adhesive

Application

Application

Precautions

Package

Waterproof Level

IP30 : Non waterproof

WS2812B IC G R B?NOT RGB? R B?NOT RGB? DC5V Black/White DC5V10A (100W) FT/reel 1 meters/reel Waterproof level: IP30/IP65/IP67 There is no double side tape on IP67. IP67 has NO adhesive on its back. Using voltage DC5V, higher than 5V will destroy it. add DC5V every 16.4FT, so there is a solder point each 50cm(1.6FT) on strip. Power adapter or controller is not included ?Please use DC5V power supply? Brand:BTF-LIGHTINGIC type :Color order :Gray level: 256View angle: 120°Input voltage:Color: full color 24-bitLED strip width: IP30 IP65 :12mmLED strip width : IP67:14mm( include silicone sheathing)FPCB board color: Power:0.1W~0.3W/LED 10W~30W/3.3ftRecommended power supply?Standard Reel Length:3.3Model: WS2812 strip 5050rgb chipsOperating Temperature: -20 ~ +40°CLength xWidthx Height?IP30:1000mmx12mmx2mm IP65:1000mmx12mmx3mm IP67:1000mmx14mmx3.85mmDouble Side Tape: IP30/IP65 .Light up 1 color?red or green or blue) 0.1W/LED . Light up 2 colors (red+green) 0.2W/LED , Light up 3 colors (red+green+blue=mixed white) 0.3W/LEDEvery led has its own IC chip. One IC drives one led. The chip is built-in the LED.Biult-in IC chip .Cut it to the length you just need.Every LED can be cut off, led strip still working after it is cut.You can use this led strip to make a LED matrix panel, TV/PC backlight, laser sword or light stick. Various DIY project.3 pin connectors on both ends for easy installation, you can also add another LED on both ends.Connect them in series.Technicians are available for installation . Welcome to consultThey (IP30, IP65) has adhensive tape on the back.You can paste it on the bookcase, TV, wine cabinet, ceiling, windowsill easily.WS2812B LED strip can be used for decorating your home (e.g. dining room, bed room, upstairs, kitchen, porch, desk, and living rooms, especially great for holidays and events like Christmas, Halloween, Parties)If you need better led strip performance, you can use an Android/IOS bluetooth controller SP105E&SP110E, music controller CSY08&SP107E, WiFi controller SP108E,Alexa controller SP501E or a programmable controller K-1000C. It also works with Amaozn alexa controller .It is better to voltage because the LEDs at the far end of the strip might be dimmer due to the added resistance and voltage drop that occurs as the current flows to that end of the strip.LED strip is made by 50cm FPCB, But this minor flaw has no any bad effect on the strips performance. In fact, ALL the LED strips on the market are manufactured in half-meter lengths.1x 3 pin male connector1x 3.3 ft WS2812B 144 LED strip
