DC3‑12V Motor Remote Control Switch High Sensitivity Flexible Wireless Remote Controller for LED Strip
About this product
*Micro Motor Remote Control Switch: This is a micro motor remote control switch, the kit comes with a remote control and a receiver module, which can control the conversion of positive and negative directions
*High Sensitivity: The motor remote control switch is controlled wirelessly, with flexible control and high sensitivity
*Easy to Use and Install: The remote switch is small in size, easy to install and convenient to use, stable and reliable in performance
*Durable and Practical: The remote control is made of quality plastic material, which is durable and practical for long time
*Wide Applications: The remote control switch is suitable for LED strip, lamp bead, small LED, relay, light bulb, buzzer, small speaker, door lock, circuit board, small equipment battery powered on and off, etc.
Description
How to Use:
Interlock:
When 3 keys, press the up key to rotate forward, press the stop key to stop, press the down key to reverse, press the stop key to stop.
When 2 keys, press the up key to rotate forward, press the down key to reverse (there is no stop key, the remote control cannot be stopped).
Momentary:Â
Press and hold the up key to rotate forward, release to stop, press and hold the down key to reverse, release to stop.
Momentary Delay 5 Seconds:Â
Press and hold the up key to rotate forward, release and will stop after 5 seconds, press and hold the down key to reverse, release and will stop after 5 seconds.
Momentary Delay 1 Seconds:Â
Press and hold the up key to rotate forward, release and will stop after 1 seconds, press and hold the down key to reverse, release and will stop after 1 seconds.
Momentary Delay 3 Seconds:Â
Press and hold the up key to rotate forward, release and will stop after 3 seconds, press and hold the down key to reverse, release and will stop after 3 seconds.
Specification:
Item Type: Motor Remote Control Switch
Material: Plastic
Working Voltage: DC3-12V
Working Current: 6mA
Standby Current: 0.5mA
Working Frequency: 433.92MHZ
Maximum Load: 0.5A
Recommended Load: ?0.2A
Battery: 2 x 3V CR2016 button battery (not included)
Package List:
1 x Remote Control
1 x Receiver
Note:
Pay attention to safety protection when using.
