GOWE 2KW AC Servo Motor Drive Controller kit System 220V 9.55Nm 11A 180mm ECMA-E11820RS+ASD-A2-2023-M with 3M Cable
Availability: Pre-Order, Inquiry Price
About this product
*ECMA-E11820SS+ASD-A2-2023-M Delta 220V 2kW 9.55NM 2000r/min 180mm AC Servo Keyway Brake Motor Drive kits with 3M cable Motor+ Drive: ECMA-E11820SS+ASD-A2-2023-M Package Content: 1* 2KW AC servo Motor 1* 2KW AC Servo Drive 1* 3M Encoder Cable &Power Cable 1 Motor Specifications Model ECMA-E11820SS Product Name Electronic Commutation Motor Servo Type AC Servo Name of the Series A2
*Rated Voltage 220V Encoder Type Incremental type,20-bit Motor Frame Size 180 mm Type of Shaft Diameter and Oil Seal Keyway (with fixed screw holes), with brake, with oil seal Standard Shaft Diameter S=35mm Rated Power Output 2.0 KW Rated torque (N-m) 9.55 Max. torque (N-m) 28.65 Rated Speed (rpm) 2000 Max. speed (rpm) 3000
*Rated current (A) 11.22 Max. instantaneous current (A) 33.66 Power rating (kW/s) 26.3 Rotor inertia (¡Á 10-4kg.m2) 34.68 Mechanical constant (ms) 1.62 Torque constant-KT (N-m/A) 0.85 Voltage constant-KE (mV/(r/min)) 31.4 Armature resistance (Ohm) 0.119 Armature inductance (mH) 2.84 Electric constant (ms) 23.87 Insulation class Class A (UL), Class B (CE) Insulation resistance > 100 M ohm , DC 500 V
*Insulation strength 1.8k Vac, 1 sec Weight (kg) (with brake) 17.5Kg Radial max. loading (N) 1176 Axial max. loading (N) 490 Power rating (kW/s) (with brake) 24.1 Rotor inertia (¡Á 10-4kg.m2) (with brake) 37.86 Mechanical constant (ms) (with brake) 1.77 Brake holding torque Nt-m(min)] 10 Brake power consumption (at 20 degree ) [W] 19 Brake release time [ms (Max)] 10 Brake pull-in time [ms (Max)] 70 Vibration grade (¦Ìm) 15 Operating temperature 0~40 degree centigrade
*Storage temperature -10~80 degree centigrade Operating humidity 20~90% RH Non-condensate Storage humidity 20~90% RH Non-condensate Vibration capacity 2.5G IP Rating IP65 Approvals CE UL 2 .Drive Specifications Model ASD-A2-2023-M Product Name AC SERVO Drive Series A2
Description
ECMA-E11820SS+ASD-A2-2023-M Delta 220V 2kW 9.55NM 2000r/min 180mm AC Servo Keyway Brake Motor Drive kits with 3M cable Motor+ Drive: ECMA-E11820SS+ASD-A2-2023-M Package Content: 1* 2KW AC servo Motor 1* 2KW AC Servo Drive 1* 3M Encoder Cable &Power Cable 1 Motor Specifications Model ECMA-E11820SS Product Name Electronic Commutation Motor Servo Type AC Servo Name of the Series A2
