Pangocho Jinchao-Dc Motor Electric Linear Actuator 25mm Stroke Linear Motor, Customized Stroke DC Motor, Controller DC12V 24V Thrust 900N, Easy to Install

Dear customer: if you placed an order don't tell us that you need the product type.
such as :Voltage ,stroke ,thrust, speed
We will be delivery12v 25mm 700N 10mm/slinear actuator!
Qty:1pcs linear actuator
if you want other parameter ,you can choosethe following parameters:
12V/24V 25MM 900N 5MM/S 12V/24V 25MM 700N 10MM/S
12V/24V 25MM 600N 15MM/S12V/24V 25MM 400N 20MM/S
12V/24V 25MM 300N 25MM/S12V/24V 25MM 200N 30MM/S
12V/24V 25MM 100N 40MM/S12V/24V 25MM 100N 75MM/S
12V/24V 25MM 90N 100MM/S 12V/24V 25MM 60N 150MM/S
(Leave message which speed you need)
Product parameters:
Drive voltage: 12VDC or 24VDC (it can choose)
MaximumThrust: 90KG/900N
Minimum installation size (fully retracted around in the middle of the distance between the two holes): L1= Stroke+105 mm
Maximuminstallation size(fully extended around the middle of the distance of the two holes): L = 2xS(stroke)+105mm
Ambient temperature :-26 to +65 degree
Protection class: IP 54
Built-in limit switches(Whencompletedstroke,linear actuatorautomatically stops!)
Low noise design, noise levels below 42 db
Work rule: 10%. Loading rated thrust need 10% work rule. In 20 minutes, 2minutes work 18minutes rest.If lower load can extend work time.
Maximum self-locking force2300N

?We have matched linear actuator Mounting Brackets

The linear actuator is auxiliary driving device, widely used in medical, Medical bed, massage chair, electric foot sofa, fitness equipment, care bed, window open, ELECTRIC furniture,household, machinery, metallurgy, mine, petroleum, chemical industry, transportation, lifting, transportation, construction, food and feed processing industry. Widly application in line, massage armchair, automobile, the ventilation window open, military, stage, textile, sewage treatment and other industries equipment.
