NBPower 5000 watt hub Motor，CE 5kw ebike hub Motor， Electric Bike brushless dc hub Motor 5000w for Electric Bicycle

PRODUCT SPECIFICATIONS
Model: NC5000W electric motor
Motor power?5000w
Axle? 10mm* 16mm
motor diameter? 244mm
Voltage? 48v-96v
Magnet Height? 50mm
Stator? aluminum alloy
Windings? 700rpm @72v, 4Tx20
waterproof grade? IP54
KV? 3T motor is 12.5KV , 4T motor is 9KV.
numbers of pole pairs? 23
peak phase current ?300amp
Max torque? 190N.m
Max Efficiency? 89.80%
drop out? 149mm
Numbers of Motor phase? 3 pcs
Hall sensor? 2 sets, one is for spare
hall sensor phasing? 120 degrees
cross section of phase wire? 10mm2
temperature sensor? KTY82/122
color? dark black
N.W?12.75kgs

Package content :
? 1 x Ebike brushless hub motor 5000w ( 60v 72v 84v 96v )

Packaging Details
?Unit Type: piece
?Package Weight: 14.000kg (30.86lb.)
?Package Size: 45cm x 45cm x 25cm (17.72in x 17.72in x 9.84in)
