DAYTON Motor 1/3 HP Split Ph 1725 RPM 115 V
Availability: Pre-Order, Inquiry Price
About this product
*Shaft Dia.: 1/2"; Motor Frame Material: Steel; Motor Service Factor: 1.35
*Shaft Dia.: 1/2"; Motor Frame Material: Steel; Motor Service Factor: 1.35
*Product Dimensions : 1 x 15.4 x 7.9 inches; 0.16 Ounces
*Item model number : 6K030
*National Stock Number : 6105-01-262-2953
Description
Belt drive motor split-phase 1/3 hp nameplate rpm 1725 voltage 115 1 phase frame 56z open dripproof full load amps 5.8 60 hz cradle base motor mounting type motor mounting position all angle motor thermal protection auto ins. Class b motor service factor 1.35 ball motor bearings max ambient temp 40 degrees c motor shaft rotation cw/ccw overall length 9-15/16 in. Shaft dia 1/2 in. Shaft length 1-1/2 in. Includes 1/2 in to 5/8 in bushing
