BestTong DC 24V 101RPM Turbo Worm Gear Motor 6mm Shaft High Torque Turbine Reducer Micro Electric Motor Self-Lock
About this product
*Worm Gear Motor Rated Voltage: DC 24V Output Speed: 101RPM; Box Shaft Size: 6 x 14mm/ 0.24inch x 0.55inch(D*L); Female Thread Diameter: 2.5mm/ 0.1inch; Motor Body Size: 30 x 25mm/ 1.2inch x 1inch(L*Max.D); Gear Box Size: 45 x 30 x 25mm/ 1.8inch x 1.2inch x 1inch(L*W*T)
*The motor is Gear DC motor with micro-turbine worm, you can change the wiring-connection to change motor rotation
*Turbo worm geared motor with self-lock, in the case of motor without electric, the output axis is fixedand self-locking; The output shaft of the whole motor body is relatively short in the direction of normal speed reducer, and it is widely used in some situations where the installation dimension is required
*Suitable for small motor configuration high speed ratio, the installation space is limited occasions, large torque output
*Use in Applications: Application - Label machines, remote control curtains, automatic voltage regulators, barbecue grills, ovens, washers, waste disposal machines, household appliances, coin machines, paper currency recognizers, automatic actuators, coffee machines, towel machines, printing machines and Stage lighting
Description
It is widely used in various of occasions that require special install size.
This type is miniature Worm Gear DC Motor, which can change shaft rotation direction while the wiring positive and negative be changed.
It is also have addition two characteristics: first, With self-locking, the output shaft can not rotation when switch off, that is self-locking. Second, Gearbox output shaft and motor shaft are come to be a rectangle.
