PWM DC Motor Speed Controller, DC10-55V/40A Max 60A Stepless DC Motor Speed Controller with Forward-Brake-Reverse Switch Adjustable Potentiometer and LED Display,Continuous Current 40A
About this product
*【Regulate Range】 Input supply voltage: DC 10V-55V; Maximum current: 60A; Continuous current: 40A; Speed range: 0-100% ; Control frequency: 15KHZ.Please connect the DC power supply to use! Do not continue to use excessive load, the continuous current is 40A, and the peak value is 60A.
*【Switch Function】The PWM DC motor speed controller come with switch function. High power speed controller switch which is much more adaptable and conveniently change the motor direction.
*【Excellent Heat Dissipation Performance】 The enclosure of the speed controller for motor is an aluminum enclosure. Aluminum shell is very strong to prevent damage, holes on its side and top which are helpful for heat dissipation.
*【Easy to Operate】The stepless motor controller has a simple potentiometer knob adjusts the motor speed from 0% ~ 100% smoothly. And with LED display is accurate to show 0 ~ 100% of the motor speed. The input voltage of PWM motor speed controller should be equal to the rated voltage of the motor within 10-55V,or it will be burnt.Do not reverse the positive and negative poles！
*【Application】 The dc motor driver can be used to brush motor speed regulation, light dimming regulation in the DC circuit.Note: The motor cannot be used in electric vehicles.
Description
***Note:Â
1.DC motor governor, connected to DC power supply, not AC power;
2.The rated voltage of the product is 10-55V, and the DC power supply is connected to the governor, which should be equal to the rated voltage, or the voltage is +-10%;
3.The governor has a continuous output current of 40A and a maximum output current of 60A, which cannot be used continuously at the maximum current;
4.If the load is too high, it is easy to cause the electrical components of the motor to burn;
Specifications
Size: 5.03 x 3.85 x 0.74 inch/ 128 x 98 x 19mm
Forward & Reverse: Support
Supply/load voltage: DC 10-55V
Maximum current: 60A
Continuous Current: 40A
PWM frequency: 15KHZ
Speed Modulation Range: 0 ~ 100%
Speed Control Type: Current modulation by potentiometer (with switch)
Support Forward Reverse Rotation Control: By Forward-Brake-Reverse Switch
Note:
The digital display is the percentage of motor full speed 0-100 actual speed of non-motor
The input voltage must be divided into positive and negative
The input voltage should be equal to the rated voltage of the motor within DC 10-55V
