RedTagCanada 1pcs NodeMCU Motor Shield Board L293D for ESP-12E from ESP8266 ESP 12E kit DIY RC Toy WiFi RC Smart car Remote Control for Arduino
About this product
*Expand two-way motor-driven, two-way direct drive motor.
*Motor power, control power separation; In the experiment, by short-circuiting block the merger, the VIN and VM short, while power supply to the motor and the control board.
*When inserting ESP-12E module, please note the direction consistent with an expansion board antenna. Use of short modules that can simultaneously control board and motor.
*Motor Power (VM): 4.5V 36V, can be a separate power supply. Control power (VIN): 4.5V 9V (10VMAX), can be powered separately.
*Onboard power switch.
Description
Feature: ESP12 DEV KIT development board expansion module. Lead ESP12 DEV KIT All-function pins: SPI, UART, GPIO, AI and 3.3V power connector Expand two-way motor-driven, two-way direct drive motor Onboard power switch L293D Motor power range: 4.5V ~ 36V. Control power range: 4.5V ~ 9V. Motor power, control power separation; In the experiment, by short-circuiting block the merger, the VIN and VM short, while power supply to the motor and the control board. Technical Specifications Power input: Motor Power (VM): 4.5V ~ 36V, can be a separate power supply. Control power (VIN): 4.5V ~ 9V (10VMAX), can be powered separately Module provides short-circuit sub (short the VM and VIN), you can easily use one power (must 4.5V ~ 9V) simultaneously drive and control the motor. Logic Operating current Iss: 60mA (Vi = L), 22mA (Vi = H). Drive part of the work current Io: 1.2A. Maximum power dissipation: 4W (T = 90 ). Control signal input level: High: 2.3VVIHVIN; Low: -0.3VVIL1.5V. Working temperature: -25 ~ + 125 Drive Type: Dual high-power H-bridge driver ESP12E Dev Kit Control Port: D1, D3 (A motor); D2, D4 (B motor). Module Weight: about 20g Precautions When inserting ESP-12E module, please note the direction consistent with an expansion board antenna. Use of short modules that can simultaneously control board and motor. Package Included: 1 x L293D Wifi Motor Drive Shield Module For Arduino NodeMcu ESP8266 ESP-12E Legal Disclaimer: 1- This is a high quality compatible with Arduino products 2- Logos on chips or board and color accuracy may be different than pictures depending on the shipment from the factory. 3- Please allow slight dimension difference due to different manual measurement.
