Beilay DC Miniature Geared Motor 6v 420rpm Small Motor Motor with Terminal Mute Gear
About this product
*This Geared Motoris solidly constructed and ready to install in numerous applications.
*High-temperature resistance, high abrasion resistance, strong load capacity, sturdy and durable.
*Great replacement for the rusty or damaged DC geared motor on the machine.
*This is a DC Mini Metal Gear Motor, ideal for DIY engine, electric lock, robot model Light weight, high torque and low RPM.
*As far as possible within the specified load range, prohibit motor blocking or close to the stall state for too long time to runs. Otherwise, the motor will burn out.
Description
Specifications:
Rated Voltage: DC 12V
Reduction Ratio: 1: 172
No-Load Speed: 30RPM
Rated Torque: 6Kg.cm
Rated Current: 0.6Amp
D Shaped Output Shaft Size: 6*14mm (0.24" x 0.55") (D*L)
Gearbox Size: 37 x 29.5mm (1.46" x 1.16") (D*L)
Motor Size: 36.2 x 33.3mm (1.43" x 1.31") (D*L)
Application:
Vending equipments, pan camera, slot machine, money detector, coin refund devices, automatic doors, peritoneal machine, toys motor etc.
PLEASE NOTE:
1. Use tolerance: Pay attention to the use of voltage and current range, otherwise the motor performance and motor life will decline.
2. Handling motors: Gently, as far as possible the use of motor shell part.
3. Motor wiring: Red lead to the positive electrode, black lead to the negative pole, if reversed, the motor rotation in the opposite direction.
4. Overload: As far as possible within the specified load range, prohibit motor blocking or close to the stall state for too long time to runs. Otherwise, the motor will burn out.
5. Motor storage:
Storage temperature: 0? - 40?;
Storage humidity: 15% -90% RH.
6. Motor use temperature: 0? - 70?
