Motor Speed Controller ，12V 24V PWM Regulator Switch Control Module CW CCW Rotation DC6V
Availability: Pre-Order, Inquiry Price
About this product
*Better Control: By adjusting the pulse width modulation, that is PWM, the regulator can easily control the motor speed.
*Simple Working: The PWM frequency is 21kHz, and the duty cycle can be adjusted from 0% to 100%, reliable and convenient.
*Reliable Using: Also comes with switch potentiometer to control the CW rotation, CCW rotation and stop of the DC motor.
*Easier Viewing: 3 digit LED display screen enables a clear viewing on the output, making the operation much simpler.
*Easy to Install: Designed to have a light weight as well as 57 x 37 x 21mm compact size, the installation is very easy.
Description
Specification:
Item Type: Motor Speed Controller
Input Power Voltage: 6V - 24V DC
PWM Frequency: 21kHz
Adjustable Duty Cycle: 0%-100%
Rated Current: 30A
Potentiometer: With switch function.
Digital Display: The display range of 3 digit LED display is 000-100. For example, 055 is displayed to indicate that the PWM output duty cycle is 55%.
Product Size: Approx. 57 x 37 x 21mm / 2.24 x 1.46 x 0.83in
Package List:
1 x Motor Speed Controller
