Thread Shaft Motor, DC 12V 400RPM N20 Micro Gear Motor with Long M4x55mm Lead Screw Reducer Thread Output Shaft 16mm Shaft with Gear Box
Availability: Pre-Order, Inquiry Price
About this product
*♚ [Long Output Shaft] Long output shaft, suitable for various low-speed motor models such as precision robot, airplane model.
*♚ [Durable] The torque is large, all the metal gears are durable and not easy to damage.
*♚ [Quiet Operation] Small size, large torque and small current, with higher reduction ratio, the motor runs quieter.
*♚ [Self-drilling] The output shaft is a tapping screw, you can easily make a movable transmission structure with a nut.
*♚ [Applicable] This product can be used in electronic locks, automatic locks, smart robots, model vehicles, etc.
Description
Description:
Long shaft gear motor is a high quality gear motor. The gear motor adopts full metal structure including mental gear reducer with precise micro gear. This gear motor has large torque and small noise, can be used on electronic locks, intelligent model cars, robots, etc.
Specifications:
Motor Length: 16mm / 0.63"
Gear Box Length: 9mm / 0.35"
Cross Section Dimension: 12mm x 10mm / 0.47 x 0.39"
Output Shaft Length: 55mm / 2.16"
Output Shaft Diameter: M4
Rated Voltage: DC 12V
Rated Current: 0.17A
Rated Torque: 0.5 KG.CM
Original Speed: 20000RPM
Output Speed: 400RPM
Error: ± 10%
Weight: 18g(approx.)
Package Includes:
1 x Gear Motor
Note:
1. Please allow 1-3mm error due to manual measurement. Thanks for your understanding.
2. Monitors are not calibrated same, item color displayed in photos may be showing slightly different from the real object. Please take the real one as standard.
