2 Pack 10A 12V-40V DC Motor Speed Controller 12V 24V PWM Variable Speed Regulator Governor Switch With Speed Control Knob for Arduino
About this product
*2 Pack DC 10A 12V-40V motor speed controller, high efficiency, high torque, low heat radiation.
*Working Voltage: DC 12V - DC 40V;Rated Current: 8A;Max Current: 10A;Static Current: 0.02 A ( Standby ).
*PWM Duty Cycle: 10% -100%;Control Power: 0.01 - 400W;PWM Frequency: 13KHz.
*Function: With power supply reverse polarity protection, over-voltage protection, 10A standard fuse over-load protection.
*With Speed Control Knob to control motor speed.
Description
Specification: Work Voltage: DC 12V-40V Rated Current: 8A Max Current: 10A Quiescent Current: 0.02A (Standby) Output Voltage: Approx.0%-100% of input voltage Speed Range: 10%-100% PWM Frequency: 13KHz PWM Pulse Width Speed Range: 10%-100% Power Range: 0.01-400W Knob Potentiometer: Resistance B100K, Trepanning 8mm Fuse Wire: 5x20mm 10A Note: DC power supply polarity can not be inversed, otherwise is may damage speeder. Not suitable for AC power supply. Package Included? 2*12V-40V 10A PWM DC Motor Speed Controller
