DSE5210 Auto Controller DSE 5210 for Generator Genset Alternator

Auto Controller DSE5210 DSE 5210 for Generator Genset Alternator



AUTO START MODULES



The DSE 5210 Genset Auto Controller designed to automatically start and stop diesel

and gas generating sets that include non electronic engines. The module also provides excellent engine monitoring and protection features.



The DSE 5210 Controller has the ability to monitor under speed, over speed, charge failure, emergency stop, low oil pressure, high engine temperature, fail to start, fail to stop, under/over generator volts,over current, under/over generator frequency, low/high DC battery volts, low fuel alarm and loss of the speed sensing signal. The module displays fault conditions on the LCD display and via the LED indicators on the front.



DSE Genset Controller DSE5210 include RS232 or RS485 communications capabilities for linking to a PC, sending SMS messages and interfacing with new and existing building management systems.



OPERATION

DSE5210 is operated using the front STOP, AUTO and MANUAL push buttons.

CONFIGURATION

The modules can be configured using the front panel buttons or by using the DSE810 interface and PC software.



PC Software

DSE5210 Auto Start Generator Controller has the ability to be controlled, configured and monitored from a remote PC, using the DSE810 interface.



Application: >10 KW gas & diesel generator started with battery
