TEN-HIGH PLC Controller, Stepping Servo Motor Controller, Pulse Generator, Dual Axis Axis Controller LCD Controller.
Availability: Pre-Order, Inquiry Price
About this product
*The controller uses high-performance 32-bit CPU, the drive device using subdivision stepper motor or servo motor, Equipped with LCD Monitor, Fully closed touch operation keyboard, the system is high reliability, high precision, low noise, simple operation.
*The controller uses high-performance 32-bit CPU, the drive device using subdivision stepper motor or servo motor, Equipped with LCD Monitor, Fully closed touch operation keyboard, the system is high reliability, high precision, low noise, simple operation.
*Date First Available : September 28, 2017
*Manufacturer : TEN-HIGH
Description
Power supply: DC 24V
Control axes: 2 axes
Maximum output frequency: 150KHz
Programming instructions: a total of 25 instructions
Number of programs: 480
Electronic gear: Molecule: 1-99999, Denominator: 1-99999
Minimum data unit: 0.001mm
High performance, high speed 32 bit
LCD monitor (192x64)
Dimensions: length x width x thickness 174x94x45mm
Inlet size: length x width 162x84mm, front panel thick
